Betaine hydrochloride dryer
Introduction:Betaine hydrochloride is a kind of high efficiency, high quality and economical nutrient additive, which is widely used in livestock, poultry, aquaculture and various pet animal feeds, and its function is the same as betaine.
Tel:13906123780
Detail


Application customer

Shandong Jujia


Project description

Betaine hydrochloride is a kind of high efficiency, high quality and economical nutrient additive, which is widely used in livestock, poultry, aquaculture and various pet animal feeds, and its function is the same as betaine.


versatile

1. Provide methyl group as a methyl donor. The efficient methyl donor can partially replace methionine and choline chloride and reduce feed cost. Its methyl supply efficiency is 1.8 times that of 50% choline chloride and 2.6 times that of D/ L-methionine.

2. Participate in fat metabolism and promote protein synthesis. The addition of betaine hydrochloride to pig feed can increase the eye muscle area, reduce the average thickness of pig backfat, and improve the lean meat percentage and carcass quality. Adding in chicken feed can improve the carcass quality and breast muscle mass of broilers, reduce abdominal muscle deposition and reduce feed to meat ratio.

3, with feeding activity. Betaine hydrochloride is a quaternary ammonium alkaloid, which can stimulate the sense of smell and taste of animals, promote animal feeding, improve the palatability and utilization of food, increase feed intake and daily weight gain, and is the main attractant of feed. It is highly attractive to fish's sense of smell.

4. Buffer material for sudden osmotic pressure change. When osmotic pressure changes drastically, betaine hydrochloride can effectively prevent cell water loss, improve the function of NA/K pump, improve the tolerance of objects to water shortage, high temperature, high salt and high osmotic environment, stabilize enzyme activity and the function of biological macromolecules, so as to regulate the water ion balance of animal intestine, maintain intestinal function and slow the occurrence of diarrhea. At the same time, betaine hydrochloride can also improve the survival rate of seedlings, especially young shrimp and fish fry.

5. It has synergistic effect with anticoccidial drugs and improves curative effect. The combination of anticoccidian drugs and betaine hydrochloride can buffer the change of ion balance, so as to improve the nutrient absorption rate and promote the growth of poultry.

6. Protective vitamins. Betaine hydrochloride does not destroy the vitamin in feed, and betaine hydrochloride in premix and concentrate has a certain protective effect on the stability of VA and VB, which improves the use effect.

7, pharmaceutical industry raw materials, prevention of liver disease.

8, can be used for gastric acid deficiency, atherosclerosis and liver diseases. Can increase fat metabolism, inhibit fat deposition in the liver.

9, it is an important raw material of the veterinary drug tylobacterin.


Material description

Betaine hydrochloride, is a general term for a class of organic compounds, also known as betaine hydrochloride, is a white to slightly yellow crystalline powder, sour taste, moisture absorption, easy to dissolve in water, ethanol, difficult to dissolve in ether, trichloromethane, alkali reaction. Betaine hydrochloride is a kind of high efficiency, high quality, economic, widely used in livestock, poultry, aquaculture feeding and growth promotion nutrient additive.


Physical property

White to slightly yellow crystalline powder, sour taste, moisture absorption, soluble in water, ethanol, difficult to dissolve in ether, trichloromethane, alkali reaction.


Working principle

The material enters the machine from the feed port and jumps forward on the air distribution plate under the action of the vibration force provided by the vibration motor or other means. At the same time, the air is heated to a certain temperature after being filtered and enters the downwind chamber of the dryer through the tuyere. Under the dual action of the vibration force and the hot air flowing through the air distribution plate, the material is in a suspended state and contacts with the hot air flow. The intense turbulence between the material particles and the hot medium strengthens the heat and mass transfer process. The dried product is discharged from the discharge port, and the evaporated water and waste gas are recovered by the cyclone separator and discharged into the atmosphere. The lower bed body provides a stable air chamber with a certain pressure for the bed. Adjust the induced draft fan, so that the upper part of the bed material in the upper box to maintain a small negative pressure, maintain a good dry environment and prevent dust leakage.


Product characteristics

1. The material is heated evenly, the heat exchange is sufficient, the drying strength is high, and the energy saving is about 30% compared with the ordinary dryer. Vibration source is driven by vibration motor, running balance, easy maintenance, low noise, long life. Steady flow, no dead Angle and blow through phenomenon. It has little damage to the surface of the material, and can be used for fragile drying, and does not affect the working effect when the material particles are irregular.

2. The fully enclosed structure effectively prevents cross-pollution between materials and air, and the working environment is clean. Good adjustability, wide adaptation surface, material layer thickness, moving speed in the machine and amplitude changes can be stepless adjustment.

3. Due to the application of vibration, the minimum fluidizing gas speed can be reduced, which can significantly reduce the air demand, and then reduce the dust layer entailing, supporting heat sources, fans, cyclone separators, etc., can also be reduced accordingly, complete sets of equipment reduced, energy saving effect is obvious. The in-machine residence time can be easily changed by adjusting vibration parameters. The operation of the piston flow reduces the requirements of material particle size uniformity and regularity, and it is easy to obtain uniform dry products.
