Hormone drugs are drugs that take human or animal hormones (including organic substances with the same structure and principle of action as hormones) as effective ingredients. According to the material parameters provided by the customer and the results of our research and test, the screw belt vacuum dryer is selected.

Generally, the "hormone drugs" in the doctor's mouth are generally "adrenal glucocorticoids" when there is no special designation, and the hormones can be divided into: glucocorticoids, adrenal corticosteroids, norepinephrine hormones, progesterone, estrogen, androgens, etc. Say. Other hormone drugs are commonly used by their classification names, such as "male hormone", "insulin", "growth hormone" and so on.

GLZ series vacuum belt dryer is a new generation of vacuum drying and mixing equipment developed by our factory to digest and absorb similar foreign products. The equipment integrates drying, crushing, vacuum decompression and powder mixing. It is composed of motor, reducer, frame, mechanical seal, filter, spiral belt agitator, cone-shaped cylinder with jacket heating and discharge valve. It can realize the whole process of closed continuous operation, and its drying efficiency is 3 to 5 times that of the SZG series double-cone rotary vacuum dryer of the same specification, which is mainly used in powder drying in pharmaceutical, chemical, pesticide, food and other industries.

The main body of the equipment is upright and stationary, and the heated spiral belt carries out circular stirring and lifting movement. After the material enters the dry chamber, the jacket and the stirred spiral belt are used to contact and heat the material. The material is stirred by the spiral belt in an orderly manner, which turns over, lifts and falls, so that the material constantly contacts the wall of the heating chamber and carries out forced heat exchange. To achieve the purpose of rapid drying.

1, equipment and material contact parts are made of "GMP" requirements materials.

2, the top drive, the equipment in the feeding, drying, mixing, discharging process without contact with the outside air, no leakage, no dead Angle.

3. The design, manufacture and testing of the equipment cavity shall be carried out in accordance with the requirements of the pressure vessel.

4, the rotating connection part adopts the double-end dry mechanical seal approved by GMP requirements, and no foreign matter falls.

5, the chamber and the mixing paddle are equipped with heating runner, and the mixing paddle drives the material for heat exchange orderly and evenly, and the heating area is large.

6, the material is not hung on the wall during the drying process.

7. Finish of the part in contact with the material :Ra≤0.4um(surface passivation or electrolytic polishing).

8. Set the line sampler.

9, set the valve top dead Angle back mouthpiece.

10, stable operation, protect the crystal shape.

11, low energy consumption cost, high mixing efficiency.

12, simple operation, easy maintenance.
