Our company uses high-end YPG pressure spray dryer, can achieve the drying of polyglucose and granulation at the same time. According to the process requirements, the pressure, flow rate and the size of the nozzle can be adjusted to obtain the required spherical particles in a certain proportion.

polydextrose (polydextrose) is another name for water-soluble dietary fiber. It is white or white solid particles, easily soluble in water, solubility 70%, PH value of 10% aqueous solution is 2.5-7.0, no special taste, is a food component with health function, and can supplement the water-soluble dietary fiber required by the human body. After entering the human digestive system, it produces special physiological and metabolic functions, thereby preventing constipation and fat deposition.

Polyglucose has the function of regulating lipid metabolism, lowering cholesterol, reducing sugar absorption, preventing and treating constipation, detoxifying and nourishing appearance, and is widely used in health care products, flour products, meat products, dairy products, beverages, wine, condiments, frozen foods, snack foods, etc.

The working process of the unit is to input the material liquid through the diaphragm pump at high pressure, spray the mist droplets, and then flow down with hot air. Most of the powder particles are collected by the discharge port at the bottom of the tower, the exhaust gas and its tiny powder are separated by the cyclone separator, the exhaust gas is discharged by the extraction fan, and the powder is collected by the pollinator cylinder located at the lower end of the cyclone separator. The fan outlet can also be equipped with a secondary dust removal device. The recovery rate is more than 96-98%.

1, the drying speed is fast, the surface area of the material liquid is greatly increased after atomization, in the hot air stream, 95% to 98% of the water can be evaporated instantly, the drying time only takes ten seconds to tens of seconds, especially suitable for the drying of heat-sensitive materials.

2, all products are spherical particles, uniform particle size, good fluidity, good solubility, high product purity, good quality.

3, wide range of use, according to the characteristics of the material, you can dry with hot air, you can also use cold air granulation, strong adaptability to the material.

4, simple and stable operation, convenient control, easy to achieve automated operations.
